Description
The P6EL-W is a 4-inch smart control panel specifically designed for US standard wall boxes. This panel combines a powerful Zigbee gateway with 3 local relays, enabling comprehensive control of lights, curtains, air conditioners, and all smart home devices through a single intuitive interface.
Key Features
- US Standard Compatibility: Designed for US wall boxes with 83mm bolt hole spacing, simple in-wall installation.
- Zigbee Gateway: Built-in Zigbee gateway connects and controls 100+ Tuya smart devices including switches, sensors, and plugs.
- 3 Local Relays: Built-in 3 relays (2A per gang, 6A total) for direct lighting control.
- APP Remote Control: Full remote access and scene configuration via Tuya App.
- Auto Light Sensor: Automatically adjusts screen brightness based on ambient light.
- Built-in Speaker: 1W mono speaker for voice feedback and audio playback.
Specifications
| CPU: RK3308B Quad-core Cortex-A35 | OS: Linux 4.4.143 | RAM: 128MB DDR3 | ROM: 256MB Flash | Screen: 4-inch 480×800 multi-touch | Bluetooth: BLE 4.2 | WiFi: 2.4GHz 802.11b/g/n | Zigbee: 802.15.4 | Relays: 3×2A (6A total) | Speaker: 1W | Power: 100-240VAC 50/60Hz | Working Temp: 0°C~40°C | Dimensions: 120×74×11mm (without base) | Bolt Hole Spacing: 83mm | Net Weight: ~186g |
